Multipins Circular Push Pull Connectors, Multi Pin Plug Right Angle Shaped

Name: Multipins Circular Push Pull Connectors Multi Pin Plug Right Angle Shaped
Brand: RAYMO
Price: 1 USD

Quality Multipins Circular Push Pull Connectors, Multi Pin Plug Right Angle Shaped for sale

Brand Name : RAYMO

Model Number : FGG.00B.302.CLAD52Z

Certification : ISO:9001-2015, CE ,RoHS2.0, SGS, REACH

Place of Origin : SHENZHEN,CHINA

MOQ : 5 Piece/Pieces

Price : Negotiable

Payment Terms : Western Union, L/C, D/A, D/P, T/T

Supply Ability : 5000Pieces/ Week

Delivery Time : 5-7wds

Packaging Details : Plastic Bag & Carton

Type : Elbow plug circular push pull connector

Contact no. : 2,3,4,5,6,7,9pins are available

Insulator : PPS, PEEK is available

IP Ranking : IP50

Endurance : 5000 times push pull

Color : Silver-white

Contact Now

00B circular push pull connector 2 pin FHG multipins plug right angle connector m7 elbow connector

Parts Description

RAYMO P/N=RM-FHG-00B-302-JS27Z= LEMO FHG.00B.302.CLAC27Z
Elbow circular push pull connector, natural shell, 2pins, male solder contacts
Different shell size from 00B to 4B
Multipoles contacts from 2pins to 32 pins

Main Features

Size/Series	0B/1B/2B/3B/4B (Metal (Mechanical Keying))
Shell Style/Model	Ebow 90 degree plug
Keying	1 key (alpha=0, plug: male contacts, receptacle: female contacts)
Housing Material	Brass (chrome plated) shell and collet nut, nickel plated brass latch sleeve and mid pieces
Configuration	Brass (gold plated)
Insulator	PPS
Contact Type	Solder
Endurance (Shell)	5000 mating cycles
Temp (min)	-40 deg
Temp (max)	125 deg C
Humidity (max)	<=95% [at 60 deg C / 140 F]
Vibration	15 g [10 Hz - 2000 Hz]
Shock Resistance	100 g [ 6 ms]
Salt Spray Corrosion	>144 hr
IP Rating	50

Company Intrce

Raymo technology offer a full ranfe of ruggrf self-latching push pull connectors used in a vatirety of demanding enviroments, Reasrch, Communications. Broadcast connector,Machines, Defense, Robotic, Aerospace, Public Sector, Information Systems, Motorsoirt, Miscellaneous applications. We can crosse Lemo Cariantions and size

Application

Test & measurement LIKE Automation
Extreme LIKE Nuclear
Medical LIKE Therapy applications
Transport LIKE Automotive
Defense & Security LIKE Computers
Broadcast LIKE High Speed Camera
Energy LIKE TV and motion picture

Pictures of EGG socket

Multipins Circular Push Pull Connectors, Multi Pin Plug Right Angle Shaped

Contacts ans shell size

Shell size	Contacts no. (Both with Solder & PCB type)
Shell size	Contacts no. (Both with Solder & PCB type)
RM-00	2	3	4
RM-0B	2	3	4	5	6	7	9
RM-1B	2	3	4	5	6	7	8	10	12	14	16
RM-2B	2	3	4	5	6	7	8	10	12	14	16	19
RM-3B	3	4	6	8/(6+2)	9(8+1)	10	12	14(13+1)	14	16	18	21	26	30	32
RM-4B	7	10	24

Advantages

Sample Free:1-2 PCS
Fast lead time: 3-5 work days if the QTY is under 200 PCS
Flexiblity payment way:T/T,PayPal,Westunion,Credit card
24 hours service for clients
Competitive price & stable prction
Certified CE and RoHS
OEM/ODM/Cable Assemble
World-class customer service

Exhibition

2020.11 Electronica Munich, Germany
2019 9.24-9.26 Testing Expo, Shanghai
2018 11.12-11.15 Electronica Munich, Germany
2017 9.11-9.16 NAB Show,Netherlands
2016 4.11-4.15 HK Fair
2015 10.2-10.7 ICEEB, Brasil
2014 10.11-10.15 HK Fair
2014 4.11-4.15 HK Fair

Why you need buy compatible connector?

100% compatible lemo connector,
Help you save at least 50% cost
Cable assembly offer,help you save prction time.

RFQ

1. Are your company a professional manufacturer?
Raymo: Yes, we specialized in prcing circular connectors and cable assembly since 2010.Our factory is SGS audited manufacturer and served global customers for more than 9 years.
2. What is the MOQ?
Raymo: No MOQ limited, small order is accepted, all is depend on customer real needs.
3. Free sample:
Raymo: Available. Any needs, please contact us.
4. What about the delivery time?
Raymo: sample for 3-5 working days, mass prction for 5-7 working days.
5. What is your payment terms?
Raymo: 100% T/T deposit when customer place order.
6. Does your prct have any warranty?
Raymo: Yes, all of our connectors can work normally after 5000 cycles mating; our factory
has instruments to tested them before shipping.
Damage due to misuse, treatment and unauthorized modifications and repairs are not covered by our warranty.

If you couldn't find exact items you want,PLS kindly email us exact models you need, best price & each model specification details will be provided to you soon. Solve the original brand's high cost and long lead time!
